Texas Instruments TAS6584-Q1 EVM User Manual

Table 3-1. Bill of Materials (continued)
Designator Qty Value Description PackageReference PartNumber Manufacturer
(1)
Alternate PartNumber
U13 1 Automotive Catalog 96-kHz 24-Bit Digital Audio
Interface Receiver, 50 ps Jitter, 3.3V, -40 to 85
degC, 28-Pin TSSOP (PW), Green (RoHS & no
Sb/Br)
PW0028A DIR9001IPWQ1 Texas Instruments
U16 1 5.5V, 4A, 16mΩ Automotive Load Switch With
Adjustable Rise Time and Optional Quick Output
Discharge, DSG0008B (WSON-8)
DSG0008B TPS22965TDSGRQ1 Texas Instruments TPS22965TDSGTQ1
U17 1 1-A High Efficiency Step-Down Converter in
SOT23-5 Package, DBV005A, DBV0005A (SOT-5)
DBV0005A TLV62568DBVR Texas Instruments TLV62568DBVT
U18, U19 2 Single Output LDO, 400mA, Adj.(1.2 to 5.5V),
Cap free, Low Noise, Reverse Current Protection,
DBV0005A (SOT-23-5)
DBV0005A TPS73618DBVR Texas Instruments
U20, U22, U23 3 4-Bit Dual-Supply Bus Transceiver With
Configurable Voltage-Level Shifting and 3-State
Outputs, RSV0016A (UQFN-16)
RSV0016A SN74AVC4T774RSVR Texas Instruments
U21 1 Dual Bi-Directional I2C-Bus and SMBus Voltage
Level-Translator, 0 to 5.5 V, -40 to 85 degC, 8-pin
X2SON (DQE), Green (RoHS & no Sb/Br)
DQE0008A PCA9306DQER Texas Instruments
Y1 1 OSC, 24 MHz, 2.25 - 3.63 V, SMD 2x1.6mm ASTMLPA-24.000MHZ-EJ-E-T Abracon Corporation
Y2 1 Crystal, 12.288 MHz, 18pF, SMD Crystal, 2.5x1x3.2mm ABM8G-12.288MHZ-18-D2Y-T Abracon Corporation
C8, C9, C151, C152, C153, C154,
C155, C156
0 0.47uF CAP, CERM, 0.47 uF, 50 V, +/- 10%, X7R, AEC-
Q200 Grade 1, 0805
805 GCM21BR71H474KA55L MuRata
C141, C142, C143, C144, C145,
C146, C147, C148
0 470pF CAP, CERM, 470 pF, 100 V, +/- 10%, X7R, 0603 603 06031C471KAT2A AVX
C149, C150 0 180pF CAP, CERM, 180 pF, 50 V, +/- 5%, C0G/NP0, 0603 603 06035A181JAT2A AVX
FID1, FID2, FID3, FID4, FID5, FID6 0 Fiducial mark. There is nothing to buy or mount. N/A N/A N/A
J6, J14 0 Header, 100mil, 2x1, Gold, TH Sullins 100mil, 1x2, 230 mil
above insulator
PBC02SAAN Sullins Connector Solutions
R72, R76 0 4.99k RES, 4.99 k, 1%, 0.063 W, AEC-Q200 Grade 0,
0402
402 CRCW04024K99FKED Vishay-Dale
R78, R79, R80, R81, R82, R83,
R84, R85
0 5.76 RES, 5.76, 1%, 0.125 W, AEC-Q200 Grade 0,
0805
805 CRCW08055R76FKEA Vishay-Dale
R86, R91 0 12.7k RES, 12.7 k, 0.1%, 0.1 W, 0603 603 RG1608P-1272-B-T5 Susumu Co Ltd
R87 0 42.7k RES, 42.7 k, 0.5%, 0.1 W, 0603 603 RT0603DRE0742K7L Yageo America
R88, R89, R90 0 0 RES, 0, 5%, 0.1 W, 0603 603 RC0603JR-070RL Yageo
R92 0 3.65k RES, 3.65 k, 0.1%, 0.1 W, 0603 603 RG1608P-3651-B-T5 Susumu Co Ltd
(1) Unless otherwise noted in the Alternate PartNumber and/or Alternate Manufacturer columns, all parts may be substituted with equivalent.
TI Confidential - Maximum Restrictions
Schematic and Bill of Materials www.ti.com
20 TAS6584-Q1 EVM User's Guide SLOU527 – DECEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
