Premier 412/816/832 Quick Guide
INS184-8 5
All Output Types
Menu: Panel Outputs Menu:
Expander 2 Outputs
Menu:
Fast Format/Speech Channels Menu:
Expander 3 Outputs
Menu:
Expander 1 Outputs Menu:
Keypad Outputs
Partitions Attributes
1: Part 1
2: Part 2
3: Part 3
4: Part 4
5: User Test
6: Inverted
7: Latching
8: Pulsed
Output Programming
Output Group
0: Not Used 1: System 2: Partition 3: Zone
System Output Types Partition Output Types
00: Courtesy
01: Successful
Transmission
02: Log 80% Full
03: Program Mode
Selected
04: Download In Progress
05: Timed Arming
Countdown
06: Zone Soak Test Active
07: Zone Soak Test Failed
08: Latched AC Fail
09: Telephone Line Fault
10: Smoke Alarm
11: Box/Auxiliary Tamper
12: Date Time Loss
13: Zone Trouble/Tamper
14: Keypad
Tamper/Removed
15: Service Fault
16: Output 1 Fault
17: Output 2 Fault
18: Siren/Bell Fault
19: Smoke Sensor Fault
20: Auxiliary Fuse Fault
21: Latched Battery Fault
22: Service Required/Test
Fail
23: Fail To Communicate
24: Control Timer 1 Active
25: Control Timer 2 Active
26: Control Timer 3 Active
27: Control Timer 4 Active
28: PC Output 1
29: PC Output 2
30: Walk Test
31: Confirmed Alarm
32: ARC 2 Active
33: Zones Locked Out
34: AC Fail
35: Battery Fail
36: Poll Timer
00: PA Alarm
01: Duress Alarm
02: Burglar Alarm
03: Medical Alarm
04: 24Hr - Water Alarm
05: 24Hr - Gas Alarm
06: 24Hr - Low Temp Alarm
07: 24Hr - High Temp Alarm
08: Tamper
09: Trouble
10: Fire
11: Trouble/Tamper
12: Bell
13: Strobe
14: Entry
15: Exit
16: Armed
17: Stay Armed
18: Ready
19: Bypass
20: Sensor Reset on Exit
21: Sensor Reset on Reset
22: Single Pulse on Arming
23: Double Pulse on Arming
24: Chime
25: Door Strike
26: Cross Zone Time Active
27: Single Pulse on Disarming
28: Reset Required
29: Acknowledgement Required
30: Confirmed Alarm
31: Alarm Abort
32: Away Armed
33: Away Armed/Exit
34: Detector Latch
35: Armed/Alarm
36: Arm Failed
37: All Armed
Zone Output Types (Mimic)
Zone Output Types (Alarm)
01: Zone 01 Mimic
02: Zone 02 Mimic
03: Zone 03 Mimic
04: Zone 04 Mimic
05: Zone 05 Mimic
06: Zone 06 Mimic
07: Zone 07 Mimic
08: Zone 08 Mimic
09: Zone 09 Mimic
10: Zone 10 Mimic
11: Zone 11 Mimic
12: Zone 12 Mimic
13: Zone 13 Mimic
14: Zone 14 Mimic
15: Zone 15 Mimic
16: Zone 16 Mimic
17: Zone 17 Mimic
18: Zone 18 Mimic
19: Zone 19 Mimic
20: Zone 20 Mimic
21: Zone 21 Mimic
22: Zone 22 Mimic
23: Zone 23 Mimic
24: Zone 24 Mimic
25: Zone 25 Mimic
26: Zone 26 Mimic
27: Zone 27 Mimic
28: Zone 28 Mimic
29: Zone 29 Mimic
30: Zone 30 Mimic
31: Zone 31 Mimic
32: Zone 32 Mimic
33: Zone 01 Alarm
34: Zone 02 Alarm
35: Zone 03 Alarm
36: Zone 04 Alarm
37: Zone 05 Alarm
38: Zone 06 Alarm
39: Zone 07 Alarm
40: Zone 08 Alarm
41: Zone 09 Alarm
42: Zone 10 Alarm
43: Zone 11 Alarm
44: Zone 12 Alarm
45: Zone 13 Alarm
46: Zone 14 Alarm
47: Zone 15 Alarm
48: Zone 16 Alarm
49: Zone 17 Alarm
50: Zone 18 Alarm
51: Zone 19 Alarm
52: Zone 20 Alarm
53: Zone 21 Alarm
54: Zone 22 Alarm
55: Zone 23 Alarm
56: Zone 24 Alarm
57: Zone 25 Alarm
58: Zone 26 Alarm
59: Zone 27 Alarm
60: Zone 28 Alarm
61: Zone 29 Alarm
62: Zone 30 Alarm
63: Zone 31 Alarm
64: Zone 32 Alarm
To Next Page
