Texi Tronic 7 NF User Manual

TEXI Tronic 7 NF operation manual
11. Presser foot pressure
Warning: Turn OFF the power before starting the work as to prevent accident caused by abrupt start of the
sewing machine.
1. Loosen nut (2). As you turn presser spring
regulator (1) clockwise (in direction A), the presser
foot pressure will be increased.
2. As you turn the presser spring regulator
counterclockwise (in direction B), the pressure will
be decreased.
3. After adjustment, tighten nut (2).
4. For general fabrics, the standard height of
the presser spring regulator is 32 to 34 mm (4.5 kg).
12. Threading the machine head
Warning: Turn OFF the power before starting the work as to prevent accident caused by abrupt start of the
sewing machine
8

Texi Tronic 7 NF Specifications

General

Brand	Texi
Model	Tronic 7 NF
Category	Sewing Machine
Language	English
