TEXI Tronic 7 NF operation manual
BEFORE OPERATION
Caution: To avoid malfunction and damage of the machine, confirm the following.
•
Remove air-vent cap (red color) attached to the sewing machine bed.
•
Be sure to pour in the oil before using.
•
Before you put the machine into operation for the first time after the set-up, clean it thoroughly.
•
Remove all dust gathering during transportation and oil it well.
•
Confirm that the voltage has been correctly set
•
Confirm that the power plug has been properly connected to the power supply.
•
Never use the machine in the state where the voltage type is different from the designated one.
•
Confirm that the direction of rotation of the motor pulley is correct.
•
Do not tilt the sewing machine head toward this side since oil leakage or parts breakage occurs.
A safety switch is installed so that the sewing machine cannot be operated with the head tilted. When operate the sewing
machine, turn on the power switch after properly setting the head on the table.
1. Specifications
Needle bar stroke 32.7mm
Sewing speed 4000 rpm
Stitch length 4mm
Needle DPx5 #9 - #18
Presser foot lifter 13 mm
Oil Vaseline oil (e.g. Spirit 2)
Rated power 500W
2
