BHT-206A/B-SERIES-MM-1
5-00-00
Page 106 Rev. 14 30 APR 2013
Export Classification C, ECCN EAR99
b. Mechanical damage is not to exceed 0.005 inch
(0.127 mm) depth and 1/3 tube circumference.
c. Corrosion damage is not to exceed 0.0025 inch
(0.0635 mm) depth before, and 0.005 inch (0.127 mm) after
repair, and 1/3 tube circumference.
d. Condemn as unserviceable a tube that does not meet
these criteria.
7. Inspect bore of cyclic pivot lever assembly where stick tube
is installed for mechanical and corrosion damage. Bore damage
is not to exceed 0.002 inch (0.051 mm) for 1/4 of the
circumference. Limit of one repair per bore. Repair or replace
lever assembly as required.
8. For cyclic stick tubes considered serviceable, polish out
any acceptable damage using 400 to 600 grit abrasive cloth or
paper (C-423).
9. Thoroughly clean cyclic stick tube with water and mild
detergent to completely remove residual penetrant and
developer. Dry part completely.
BHT-ALL-SPM,
Chapter 3
10. Apply chemical film material (C-100) to bare metal area.
BHT-ALL-SPM,
Chapter 4
11. Touch up area with epoxy polyamide primer (C-204).
Where finish paint coat is required, match to original finish with
polyurethane coating (C-245).
Chapter 67 12. Install pilot and copilot, if installed, cyclic control sticks.
5-30. 1200-HOUR INSPECTION (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
