BHT-206A/B-SERIES-MM-1
5-00-00
Page 116 Rev. 14 30 APR 2013
Export Classification C, ECCN EAR99
ASB 206-05-103 FUEL VENT/PURGE FITTING FILTER CLEANING
This inspection is applicable to helicopters S/N 004
through 2123 Post ASB 206-05-103.
1. Remove the fuel valve access panel on the right side of
helicopter to gain access to the fuel vent/purge fitting (1,
Figure 5-3).
2. Disconnect the fuel tube assembly (4) from the top of the
filter (3).
3. Remove the filter (3) and discard packing (2).
4. Clean the filter (3) by back-flushing with clean fuel. Make
sure the filter is clean or replace as required.
5. Reinstall the filter (3) with new packing (2) and reconnect
the fuel tube assembly (4) to the filter.
6. Perform After Fuel System Maintenance and/or
Component Change inspection (paragraph 5-46).
7. Reinstall the fuel valve access panel on right side of
helicopter.
5-35. 24-MONTH INSPECTION (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
