BHT-206A/B-SERIES-MM-1
5-00-00
Export Classification C, ECCN EAR99
BHT-206A/B/L-Series-
CR&O
c. Main rotor mast
BHT-206A/B-M&O,
BHT-206B3-CR&O
d. Transmission top case
e. Transmission spindles, pylon support links, and deck
fittings
f. Cabin roof shell and beam at transmission mount
attachment points
g. Transmission isolation mount attachment points
h. Transmission electric chip detectors
i. Tail rotor gearbox chip detectors and gearbox
attachments
j. Tail rotor hub, blades, and attachments
NOTES:
Overtorque conditional inspection limit of this item may be changed to 110 to 130% provided the specific
conditions are met per the applicable notes.
Overtorque conditional inspection limit of this item may be changed to 130% and above provided the
specific conditions are met per the applicable notes.
If main rotor hub is 206-011-100-127 or subsequent.
If 206-075-739-115 torque gauge is installed.
If transmission is serviced with DOD-PRF-85734.
If top case is installed on transmission 206-040-002-025 and subsequent.
If the main driveshaft is 206-040-015-103 or subsequent.
5-56. OVERTORQUE (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
30 APR 2013 Rev. 14 Page 181/182
