Chapter 63 18. Examine mast for condition.
Chapter 62 and
Chapter 63
19. Ensure no sealant voids are visible around the swashplate
drive collar set. Recoat with adhesive (C-307) as required.
Chapter 29 HYDRAULIC SYSTEM
1. Examine rigid and flexible fluid lines for chafing, leaks, and
security.
2. Examine hydraulic pump for leaks and general condition.
3. Examine hydraulic reservoir for leaks and general
condition.
4. Examine servo actuators for leaks, condition, and security.
Chapter 67 5. Examine servo actuator support for condition.
ASB 206-76-1 a. If installed, inspect hydraulic actuator support
206-001-520-005 as follows:
• Visually inspect the two forward webs of the support
assembly for cracks with a 5X magnifying glass. All
cracks reported in the support assembly have
originated in the top edge of the forward web.
• If a crack is found, remove and replace the support
assembly. Notify Product Support Engineering
concerning any assembly found cracked.
6. Verify linkage pivot bolts on hydraulic servo actuators for
freedom of rotation and security.
Chapter 29 7. Examine hydraulic filter red indicator button. Button should
not be extended.
Chapter 12 8. Verify fluid level in hydraulic reservoir. Replenish as
required. Replace fluid if color has changed or if fluid emits bad
odor.
9. Examine relief valve and solenoid valve for leaks,
condition, and security.
5-16. 100-HOUR AIRFRAME PROGRESSIVE INSPECTION — EVENT NO. 1 (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
