TAIL ROTOR GEARBOX
Chapter 53 1. Examine tail rotor gearbox support for condition and
security. Pay particular attention for cracks at the gearbox
attachment holes.
Chapter 65 2. Examine tail rotor gearbox for oil leaks, condition, and
security.
3. Examine gearbox oil for evidence of contamination.
4. Examine tail rotor output shaft for condition.
5. Examine the tail rotor gearbox chip detector for
accumulated material.
Chapter 96 6. Perform operational check of the tail rotor gearbox chip
detector.
Chapter 27 TAIL ROTOR PITCH CHANGE CONTROLS
1. Examine the tail rotor pitch control mechanism for freedom
of travel throughout range and for condition and security.
2. Examine the following tail rotor pitch change components:
a. Boot for condition, security, and evidence of grease or
oil leakage.
b. Lower control mechanism rod for condition of bearings.
c. Pitch links and spherical bearings for condition and
security.
d. Crosshead for condition and security.
e. Knurled nut for condition and security and liner for
excessive play.
Chapter 96 ELECTRICAL
1. Examine all visible electrical components, wires, cables,
and connectors in the area of the tailboom for chafing, general
condition, and security.
5-18. 100-HOUR AIRFRAME PROGRESSIVE INSPECTION — EVENT NO. 3 (CONT)
