BHT-206A/B-SERIES-MM-1
5-00-00
30 APR 2013 Rev. 14 Page 45
Export Classification C, ECCN EAR99
ZONE 9 — AFT FUSELAGE
PLACARDS AND MARKINGS
Chapter 11 1. Examine the placards, decals, and markings. Make sure
they are readable, correctly applied, and in agreement with the
applicable configuration of your helicopter.
FUSELAGE (EXTERIOR)
Chapter 53 1. Examine aft fuselage for dents, cracks, corrosion,
delamination, loose or missing rivets, and condition.
2. Examine aft fuselage for indications of fuel or oil leaks.
Chapter 28 3. Examine the fuel cap for condition and security.
Chapter 96 4. Examine the grounding plug for condition.
Chapter 6 and
Chapter 53
5. Examine all fuselage drains for condition and freedom from
obstructions.
Applicable Service
Instruction
6. Examine heater and/or air conditioning inlets and outlets
for cleanliness and absence of obstructions, if installed.
Chapter 53 7. Examine baggage compartment door, seal, and latches for
operation, condition, and security.
8. Examine aft crosstube support tunnel structure for cracks,
corrosion, distortion, and loose fasteners.
Chapter 96 9. Verify operation of the baggage door ajar caution light, if
installed.
FUSELAGE (INTERIOR)
Chapter 53 1. Examine baggage compartment for condition.
2. Gain access to inside of aft fuselage through access
panels in baggage compartment and access panel located on
the aft right side fuselage:
a. Examine access panels and fasteners for condition.
5-19. 100-HOUR AIRFRAME PROGRESSIVE INSPECTION — EVENT NO. 4 (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
