a. Value must be between 15 to 32 pounds (67 to 142 N).
If out of limits, adjust to 15 to 32 pounds (67 to 142 N) and
check again.
16. Connect and secure boot, idler (drive) link, and main rotor
pitch links to outer ring.
17. Examine swashplate assembly for condition and security.
Chapter 63 18. Examine mast for condition and security.
Chapter 62 and
Chapter 63
19. Ensure no sealant voids are visible around the swashplate
drive collar set. Recoat with adhesive (C-307) as required.
Chapter 29 HYDRAULIC SYSTEM
1. Examine rigid and flexible fluid lines for chafing, leaks, and
security.
2. Examine hydraulic pump for leaks and general condition.
3. Examine hydraulic reservoir for leaks and general
condition.
4. Examine hydraulic pump splines, transmission oil pump
splines, and rotor tachometer and adapter splines for condition
and security.
Chapter 12 5. Lubricate hydraulic pump driveshaft splines, oil pump
splines, and rotor tachometer splines.
6. Examine servo actuator support for condition and security.
7. Examine servo actuators for leaks, condition, and security.
8. Verify linkage pivot bolts on hydraulic servo actuators for
freedom of rotation and security.
Chapter 29 9. Examine hydraulic filter red indicator button. Button should
not be extended.
Chapter 12 10. Verify fluid level in hydraulic reservoir. Replenish as
required. Replace fluid if color has changed or if fluid emits bad
odor.
5-22. 300-HOUR AIRFRAME PROGRESSIVE INSPECTION — EVENT NO. 2 (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
