MANUAL P/N 900000165 REV H
The following settings are not port specific:
DNS server list - comma separated list of DNS server IP addresses.
SNMP parameters - These are effective on the ports that have SNMP access enabled.
The NTP80 will send traps when a trap address is set. There are rules as to where these traps
will be sent depending on the port configurations.
If the trap address is on a subnet of a particular SNMP enabled port then the trap will only be
sent to that port. If the trap address is not on any subnet of the defined ports then the trap will
be sent to all SNMP enabled ports that have a gateway address defined. If the network is such
there are two routes to the trap address destination it will be received twice.
The NTP80 routing is such that all ports are isolated from each other.
Pressing Submit will apply the changes.
