©Copyright Task Force Tips LLC 2008-2021 5 LIY-300 January 13, 2021 Rev18
3.0 GENERAL INFORMATION
The Tornado monitor is a 2 ¼ inch waterway, 500 gpm maximum monitor. It is available in several configurations including manually
operated, electric remote or joystick controlled, and hydraulically oscillating versions.
3.1 MECHANICAL SPECIFICATIONS
.0
Figure 3.1
3.2 ELECTRICAL SPECIFICATIONS
Figure 3.2
Further specifications for Tornado RC models are shown in the Remote Control (RC) Monitor Electrical Controls Supplemental
Instructions (LIY-500).
MANUAL ELECTRIC OSC
US METRIC US METRIC US METRIC
Weight 12 lbs 5.5 kg 25 lbs 11.4 kg 27 lbs 12.2 kg
Minimum Flow Area
8.3 in
2
24.5 cm
2
8.3 in
2
24.5 cm
2
8.3 in
2
24.5 cm
2
Maximum Flow 500 gpm 1900 L/min 500 gpm 1900 L/min 500 gpm 1900 L/min
Maximum Operating Pressure 200 psi 14 bar 200 psi 14 bar 200 psi 14 bar
Operating Temperature Range of
Fluid
33°F to 120°F / 1°C to 50°C
Storage Temperature Range -40 to 150°F / -40 to 65°C
Materials ANSI A356.0-T6 Aluminum, Stainless, Nylon
Nominal Operating Voltage 12 or 24 VDC
Maximum Voltage 32 VDC
Maximum Torque (Elevation) 35 ft·lbs 50 N·m
Maximum Torque (Horizontal) 35 ft·lbs 50 N·m
Speed (Elevation) 25 deg/sec
Speed (Horizontal) 25 deg/sec
