TFT Tornado RC User Manual

1
QUICK CONNECT 3.0"NPT FEMALE ALUMINUM Y2403A
QUICK CONNECT 2.0"BSP FEMALE ALUMINUM Y2425A
CODE-RLF ALUMINUM Y2413A
2 GASKET - 2.5" HOSE COUPLING 1 V3190
3 COUPLING 2.5"NH 1 M307N
4 3/16" BALL - 302 STAINLESS STEEL 48 V2120
5 1/4-28 X ½ SOCKET SET SCREW 1 VT25-28SS500
6 BASE TILLER ALUMINUM 1 Y2410A
7 O-RING-233 2-7/8 ID X 1/8 C/S 2 VO-233
10 1/4-28 X ½ BUTTON HEAD CAP SCREW 2 VT25-28BH500
11 NAME LABEL: TORNADO MONITOR 1 Y2124
12 LABEL BRACKET 1 Y2120
13 3/8-24 X 3/8 DOG POINT 2 H515
14 WEAR DISC 2 Y4191
15 LOCKING BOLT 2 Y2318
16 1/4-20 X ½ BUTTON HEAD CAP SCREW 4 VT25-20BH500
17 LOCKING KNOB 2 Z245
20 3/8-16 X 1 SOCKET HEAD CAP SCREW 1 VT37-16SH1.0
21 THREAD ADAPTER 2.5"NH 1 Y2320ANJ
THREAD ADAPTER 1.5"NH Y2320ANF
THREAD ADAPTER 2.5"BSP Y2320ABJ
22 TILLER EXIT ELBOW ALUMINUM 1 Y2315A
23 TILLER BAR 1 Y2316
24 PEG 2 X362
25 3/8-16 X 1 3/4 STUD 1 VT37-16SD1.7
26 HANDLE BUSHING 1 Y2317
30 3/8-24 X 3/8 SOCKET SET SCREW CUP POINT 4 VT37-24SS375
31 BALL 5/16" TORLON 120 VB.312TO
32 1/4-28 X 3/16 SOCKET SET SCREW 2 VT25-28SS187
33 LOWER SECTION TILLER ALUM 1 Y2115A
# DESCRIPTION QTY PART #
QUICK CONNECT 2.0"NPT FEMALE ALUMINUM 1 Y2420A
QUICK CONNECT 2.5"NPT FEMALE ALUMINUM Y2400A
QUICK CONNECT 2.5"BSP FEMALE ALUMINUM Y2405A
QUICK CONNECT 2.5" ANSI 150 FLANGE ALUMINUM Y2430A
31
