TFT Tornado Series User Manual

2 GASKET - 2.5" HOSE COUPLING 1 V3190
3 1/4-28 X ½ SOCKET SET SCREW 1 VT25-28SS500
4 3/16" BALL - 302 STAINLESS STEEL 48 V2120
5 COUPLING 2.5"NH 1 M307N
10 1/4-20 HEX NUT 1 VT25-20NT
11 3/8 LOOP CLAMP 1 Y4655
12 WIRE CLAMP BRACKET 1 Y2135
13 1/4-20 X 3/8 BUTTON HEAD CAP SCREW 1 VT25-20BH375
14 BALL 5/16" STAINLESS 1 VB.312
15 BASE - QUICK CONNECT ALUMINUM 1 Y2415A
16 O-RING-233 2-7/8 ID 2 VO-233
20 1/4-28 X ½ BUTTON HEAD CAP SCREW 2 VT25-28BH500
21 LABEL BRACKET 1 Y2120
22 NAME LABEL: TORNADO RC 1 Y2122
23 1/4-20 X ½ BUTTON HEAD CAP SCREW 4 VT25-20BH500
24 OVERRIDE KNOB 2 Y4165
25 LOWER SECTION RC ALUMINUM 1 Y2110A
26 THREAD ADAPTER 2.5"NH MALE ALUMINUM 1 Y2320ANJ
THREAD ADAPTER 1.5"NH MALE ALUMINUM Y2320ANF
THREAD ADAPTER 2.5"BSP MALE ALUMINUM Y2320ABJ
27 EXIT ELBOW ALUMINUM 1 Y2310A
30 BLACK DOME PLUG 2 VM4124
31 BALL 5/16" TORLON 120 VB.312TO
32 3/8-24 X 3/8 SOCKET SET SCREW CUP POINT 4 VT37-24SS375
33 GREASE FITTING 2 VT25-28ZERK
34 HEADED BUSHING 2 Y4141
40 DRIVE SHAFT 2 Y4163
41 KEY; 1/8" X 1.00" 2 X225
42 WORM DOUBLE LEAD 2 Y2150
43 MALE THREADED BUSHING 2 Y2175
44 FEMALE THREADED BUSHING 2 Y2176
45 BEARING, CLASS C2 2 VM4252
46 WASHER 2 VW97X595-048
47 E-CLIP 5/8" EXTERNAL 2 VR4295
48 BEARING RETAINER 2 Y2160
50 MOTOR SUBASSEMBLY, SEE FIG 9.0C 2 Y4951
51 1/4-28 X 5/8 SOCKET HEAD CAP SCREW 10 VT25-28SH625
52 CONTROL BOX BRACKET 1 Y2130
53 CONTROL BOX SUPPORT 1 Y2131
54 CONTROL BOX SUBASSEMBLY, SEE FIG 9.0D 1
# DESCRIPTION QTY PART #
1 QUICK CONNECT 2.0"NPT FEMALE ALUMINUM 1 Y2420A
QUICK CONNECT 2.5"NPT FEMALE ALUMINUM Y2400A
QUICK CONNECT 3.0"NPT FEMALE ALUMINUM Y2403A
QUICK CONNECT 2.0"BSP FEMALE ALUMINUM Y2425A
QUICK CONNECT 2.5"BSP FEMALE ALUMINUM Y2405A
QUICK CONNECT 2.5" ANSI 150 FLANGE ALUMINUM Y2430A
CODE-RLF ALUMINUM Y2413A
33
