65
3-7-9 Fixed driven face comp
-Measure the outside diameter of the fixed
driven face bush.
-Wear limit Ø33.94mm
3-7-10 Movable driven face comp
-Measure the inside diameter of the movable
drive face.
-Wear Limit Ø34.06mm.
3-7-11 Spring
-Measure the free length of the movable
driven face spring.
-Replaced if the free length of spring is less
than 135mm.
3-7-12 Fixed driven face comp bearings
-Push out the old bearings and install the new one with the tube that has corresponding
length and suitable diameter.
