2.02 Covers
1
2
3
4
5
NOTE: Use Part Number 023-22P013-060 for LCD Front Panel (left) #4
NOTE: Use Part Number 023-22P011-060 for Front Panel (upper right) #2
NOTE: Use Part Number 023-22P015-060 for Front Panel Kit (lower right) #3
Item Part No. Description Remarks
1 720-058000-010 TOP RIGHT COVER
2 700-031803-021 TOP RIGHT PANEL
3 700-031903-021 BOTTOM FRONT COVER
4 700-031703-031 LEFT PANEL
5 720-058100-010 TOP LEFT COVER
