The Singing Machine SML385 - 13 Specifications

Page 17 of 21
No song lyrics
appear
on the TV
screen
Video cable is not connected
properly to the TV
Connect the video cable to the
Singing Machine’s VIDEO
OUT and to the TV VIDEO IN
Source selector on TV is not
set to VIDEO
Using your TV Remote to
select VIDEO input
TV does not have video line
input
Connect from VIDEO OUT of
the system to the VIDEO IN
on your
RF Modulator and
then to the TV
cable input.
Check the disc to be sure it is
a CDG.
A CDG is loaded but the
CDG indicator is not lit
Check disc to be sure it is
clean
, not scratched or
warped.
No sound from Mic
Mic volume control
Adjust Mic
volume to max,
and then re-
adjust to a
comfortable level
Mic is off
Turn on Mic with the ON /OFF
switch located on the
microphone
13 Specifications
Audio Section:
Output Power (Maximum)
Output Impedance
3.5 Watts (RMS)
3 Ohms
CD Player Section:
Frequency Response
Signal – to - Noise Ratio
Number of Programs
Sampling System
100Hz – 20 kHz
50dB
24 Steps Random Access Programming
8 Times Over Sampling
AUX IN Section
Ø3.5mm Stereo Headphone Jack
Microphone
-74dB 600 Ohms Impedance with Ø6.3mm
Dynamic Microphone
Power Section
5.8Vd.c. 2A
Dimensions (H x W x D)
33.6 x 26.6 x 23.5 cm
Weight
3.3 kgs
Specifications are typical, individual units may vary. They are subject to continuous
improvement without notice and without incurring any obligation.
