— E7 —
Connection
Connecting to Line In Jack
Connect an external device by using an
appropriate cable (3.5mm audio cable not
included) as shown.
Note: See page E19 to select and use the
Line In function.
To External Unit
AUDIO OUTPUT
/ HEADPHONE JACK
Bluetooth Mode
Press the button to easily set the
machine into bluetooth mode.
u
Disco Lights
When the unit is turned on, the Light
mode 1 is automatically activated. The
lights will light up and will synchronize
with sound when you speak or sing into
the microphone.
Press the LIGHT button for Light mode 2
which will display the light show but will
not respond to the microphone. Press the
LIGHT button once again to turn off the
Lights.
u
To Next Page
