— 6 —
Connection
Connecting to AC Power
Connecting to LINE IN Jack
Insert the small end of the AC
adapter into the DC IN Jack on
the rear of the unit. Insert the
other end (with the 2 blades) into
a conveniently located AC outlet
having 120V AC, 60Hz.
Note: Make all connections
before connecting to AC power.
Connect an external device
by using an appropriate cable
(3.5mm audio cable not included)
as shown.
Note: See page 17 to select and
use the LINE IN function.
To External Unit
AUDIO OUTPUT
/ HEADPHONE JACK
Disco Lights
1
To illuminate the disco light and
get your desired lighting effect,
slide the Disco Light DIMMER slide
switch from the MIN position to your
desired level.
1
To Next Page
