Theben KNX Series User Manual

The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 10
4.2.3 External inputs I1-I4: Switch function
No
.
Object name Function Length R W C T DPT
30 Channel I1.1
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
31 Channel I1.2
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
32 Channel I1.3
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
34 Channel I1
Block = 1 1 bit - W C - 1,001
Block = 0 1 bit - W C - 1,003
35 Channel I2.1
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
36 Channel I2.2
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
37 Channel I2.3
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
37 Channel I2.3 Send value 1 byte - - C T 5,010

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
