Theben KNX Series User Manual

The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 11
No
.
Object name Function Length R W C T DPT
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
39 Channel I2
Block = 1 1 bit - W C - 1,001
Block = 0 1 bit - W C - 1,003
40 Channel I3.1
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
41 Channel I3.2
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
42 Channel I3.3
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
44 Channel I3
Block = 1 1 bit - W C - 1,001
Block = 0 1 bit - W C - 1,003
45 Channel I4.1
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
43 Channel I4.2
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
47 Channel I4.3
Switching
1 bit - W C T 1,001
Priority 2 bit - - C T 2,001

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
