Theben KNX Series User Manual

The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 18
4.2.6 External inputs I1-I4: Blinds function
No
.
Object name Function Length R W C T DPT
30 Channel I1 Step/stop 1 bit - - C T 1,010
31 Channel I1
UP/DOWN 1 bit - W C T 1,008
UP 1 bit - - C T 1,008
DOWN 1 bit - - C T 1,008
32 Channel I1.1
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Height % 1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
33 Channel I1.2 Slat % 1 byte - - C T 5,001
34 Channel I1
Block = 1 1 bit - W C - 1,001
Block = 0 1 bit - W C - 1,003
35 Channel I2 Step/stop 1 bit - - C T 1,010
36 Channel I2
UP/DOWN 1 bit - W C T 1,008
UP 1 bit - - C T 1,008
DOWN 1 bit - - C T 1,008
37 Channel I2.1
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Height % 1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
38 Channel I2.2 Slat % 1 byte - - C T 5,001
39 Channel I2
Block = 1 1 bit - W C - 1,001
Block = 0 1 bit - W C - 1,003
40 Channel I3 Step/stop 1 bit - - C T 1,010
41 Channel I3
UP 1 bit - - C T 1,008
UP/DOWN 1 bit - W C T 1,008
DOWN 1 bit - - C T 1,008
42 Channel I3.1
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Height % 1 byte - - C T 5,001
Send percentage
value
1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
42 Channel I3.1 2 byte 9.x 2 bytes - - C T 9.xxx
