Theben KNX Series User Manual

The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 19
No
.
Object name Function Length R W C T DPT
4 byte 14.x 4 bytes - - C T 14.xxx
43 Channel I3.2 Slat % 1 byte - - C T 5,001
44 Channel I3
Block = 1 1 bit - W C - 1,001
Block = 0 1 bit - W C - 1,003
45 Channel I4 Step/stop 1 bit - - C T 1,010
46 Channel I4
UP 1 bit - - C T 1,008
UP/DOWN 1 bit - W C T 1,008
DOWN 1 bit - - C T 1,008
47 Channel I4.1
Switching 1 bit - W C T 1,001
Priority 2 bit - - C T 2,001
Send percentage
value
1 byte - - C T 5,001
Height % 1 byte - - C T 5,001
Send value 1 byte - - C T 5,010
2 byte 9.x 2 bytes - - C T 9.xxx
4 byte 14.x 4 bytes - - C T 14.xxx
48 Channel I4.2 Slat % 1 byte - - C T 5,001
49 Channel I4
Block = 1 1 bit - W C - 1,001
Block = 0 1 bit - W C - 1,003
4.2.7 External inputs I3-I4: Temperature sensor function
No
.
Object name Function Length R W C T DPT
40 Channel I3.1
Temperature actual
value
2 bytes R - C T 9,001
45 Channel I4.1
Temperature actual
value
2 bytes R - C T 9,001
4.2.8 Diagnosis and alarm objects
No. Object name Function Length R W C T DPT
50 Firmware Version 2 bytes R - C T 217,001
51 Alarm Info 6 bytes R - C T 219,001
52 Alarm Error code 4 bytes R - C T 12,001
53 Alarm Error text 14 bytes R - C T 16,000

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
