Theben KNX Series User Manual

The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 46
Designation
Values
Description
Average value betw.
heating and cooling
Same value in comfort mode
during both heating and cooling
mode, i.e.:
base set point + half dead zone
will be sent, so users of the room
will not be irritated.
Example with Base set point
21°C and dead zone of 2 K:
Average value = 21 °C+1 K =
22 °C,
but 21 °C
or 23 °C are used for control
Maximum floor temperature
18
24 °C, 26 °C, 28 °C
30 °C, 32 °C, 34 °C
36 °C, 38 °C, 40 °C
Maximum permissible floor
temperature.
Cyclical sending of current set
point
do not send cyclically
every 2 min.
every 3 min.
…
every 45 min.
every 60 min.
How often should it be resent?
18
This parameter is then only available when the external inputs for temperature measurement
are configured, i.e.
function of the external inputs I3+I4 = temperature sensor input
(see parameter page General) and use
the parameters of the
underfloor heating (sensor at I4)
when on
yes
.

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
