Theben KNX Series User Manual

The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 53
Designation
Values
Description
Until heat protection temp.
reached
24
The set point is only increased up
to the configured heat protection
temperature.
+3 K
+5 K
+7 K
The set point increase ends as
soon as the adjustment has
achieved the set value.
Send set point
adjustment
do not send cyclically
every 2 min.
every 3 min.
…
every 45 min.
every 60 min.
How often should it be resent?
24
In case of set point correction at high temperatures = only receive.

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
