Theben KNX Series User Manual

The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 58
4.7.2 Switch function I1, I2, I3, I4
Designation
Values
Description
Activate channel
no
yes
Use input?
Channel function
Switch..
Push button..
Dimming..
Blinds..
A push button is connected to
the input.
Debounce time
30 ms, 50 ms, 80 ms
100 ms, 200 ms,
1 s , 5 s, 10 s
In order to avoid a disruptive
switching due to debouncing of
the contact connected to the
input, the new status of the input
is only accepted after a delay
time.
Larger values (≥ 1s) can be used
as a switch-on delay.
Connected push button
NO contact
Opening contact
Set the Type of connected
contact.
Long button push starting at
300 ms, 400 ms
500 ms, 600 ms
700 ms, 800 ms
900 ms, 1 s
Serves to clearly differentiate
between long and short button
push.
If the push button is pressed for
at least as long as the set time,
then a long button push will be
registered.
Time for double-click
300 ms, 400 ms
500 ms, 600 ms
700 ms, 800 ms
900 ms, 1 s
Serves to differentiate between a
double-click and 2 single clicks.
Time period in which the second
click must begin, in order to
recognise a double-click.
Send cyclically
every min
every 2 min.
every 3 min.
…
every 30 min.
every 45 min.
every 60 min.
Common cycle time for all 3
initial objects of the channel.
Number of telegrams
one telegram
two telegrams
three telegrams
Each channel has 3 initial objects
and can thus send up to 3
different telegrams.
Activate block function
no
No block function.
yes
Show block function parameter
page.
Block telegram
Block with 1 (standard)
0 = enable
1 = block
Block with 0
0 = block
1 = enable

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
