Theben KNX Series User Manual

The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 66
4.7.4 Blinds function I1, I2, I3, I4
Designation
Values
Description
Activate channel
no
yes
Use input?
Channel function
Switch..
Push button..
Dimming..
Blinds..
The input controls a blinds
actuator.
Debounce time
30 ms, 50 ms, 80 ms
100 ms, 200 ms,
1 s , 5 s, 10 s
In order to avoid a disruptive
switching due to debouncing of
the contact connected to the
input, the new status of the input
is only accepted after a delay
time.
Larger values (≥ 1s) can be used
as a switch-on delay
Long button push starting at
300 ms, 400 ms
500 ms, 600 ms
700 ms, 800 ms
900 ms, 1 s
Serves to clearly differentiate
between long and short button
push.
If the push button is pressed for
at least as long as the set time,
then a long button push will be
registered.
Double-click additional function
no
No double-click function
yes
The double-click parameter page
is shown.
Time for double-click
300 ms, 400 ms
500 ms, 600 ms
700 ms, 800 ms
900 ms, 1 s
Serves to differentiate between a
double-click and 2 single clicks.
Time period in which the second
click must begin, in order to
recognise a double-click.
Activate block function
no
No block function.
yes
Show block function parameter
page.
Block telegram
Block with 1 (standard)
0 = enable
1 = block
Block with 0
0 = block
1 = enable

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
