Theben KNX Series User Manual

Typical applications
RAMSES 718 P / RAMSES 718 S 75
No.
RAMSES
718 P/S
No.
RAMSES
718 P/S
Comment
Object
name
Object
name
30
Channel I1.1
switching
45
Window
status
The windows status is detected at input E1 (window
contact) and sent to the controller (window status) via
a group address. When opening the window, the
controller changes into frost protection mode.
5.1.4 Important parameter settings
Standard or customer-defined parameter settings apply to unlisted parameters.
RAMSES 718 P/S:
Parameter page
Parameter
Setting
RTC setting
Control
Heating control only
Rotary control function
25
Blocked
Button function
26
Blocked
Operating Mode
Objects for determining the operating
mode
New: Operating mode, presence,
window status
Type of presence sensor type
(presence obj.)
Presence detectors
Channel I1
Activate channel
ON
Channel function
Switch
Number of telegrams
One telegram
Switch object 1
Object type
Switching (1 bit)
Send if input = 1
yes
Telegram
ON
Send if input = 0
yes
Telegram
OFF
Send cyclically
yes
Response after restoration of the bus
supply
update (immediately)
PlanoSpot 360 KNX:
Parameter page
Parameter
Setting
General
Channel C4 – presence
active
Channel C4 – presence
Presence switch-on
delay
5 min
Presence time delay
10 min
25
Only RAMSES 718 P
26
Only RAMSES 718 P

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
