Typical applications
RAMSES 718 P / RAMSES 718 S 78
5.2.4 Objects and links
No.
TR 648 top2
No.
RAMSES 718 P
Comment
Object name
Object name
7
C1.1 switching channel –
HVAC operating mode
13
Operating mode
preset
Switches the controller between
standby and night.
No.
RAMSES 718 P
No.
HM 6 T
Comment
Object name
Object name
18
Heating actuating
value
0
Continuous actuating
value
Actuating value for the heating
actuator.
No.
RAMSES 718 P
No.
RAMSES 718 P
Comment
Object name
Object name
30
Channel I1.1
switching
15 Window status
The windows status is detected at input E1
(window contact) and sent to the controller
(window status) via a group address. When
opening the window, the controller changes
into frost protection mode.

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
