RAMSES 718 P / RAMSES 718 S 90
6.4.1 Format of set point correction: Relative
set point correction is sent as a temperature difference.
Below the set point correction threshold (set point correction from) the value 0 is sent.
If the set point correction threshold (set point correction from) is exceeded, the set point will be
increased linearly depending on the change of the outside temperature.
Example: Calculated correction value
set point correction from: 26 ºC
Outdoor temp.
Adjustment
1 K/1 K
1 K/2 K
1 K/3 K
1 K/4 K
1 K/5 K
1 K/6 K
1 K/7 K
20°C
0 K
0 K
0 K
0 K
0 K
0 K
0 K
Correction value
21°C
0 K
0 K
0 K
0 K
0 K
0 K
0 K
22°C
0 K
0 K
0 K
0 K
0 K
0 K
0 K
23°C
0 K
0 K
0 K
0 K
0 K
0 K
0 K
24°C
0 K
0 K
0 K
0 K
0 K
0 K
0 K
25°C
0 K
0 K
0 K
0 K
0 K
0 K
0 K
26°C
1 K
27°C
2 K
1 K
28°C
3 K
1 K
1 K
29°C
4 K
2 K
1 K
1 K
30°C
5 K
2 K
1 K
1 K
1 K
31°C
6 K
3 K
2 K
1 K
1 K
1 K
32°C
7 K
3 K
2 K
1 K
1 K
1 K
1 K
33°C
8 K
4 K
2 K
2 K
1 K
1 K
1 K
34°C
9 K
4 K
3 K
2 K
1 K
1 K
1 K
35°C
10 K
5 K
3 K
2 K
2 K
1 K
1 K
36°C
11 K
5 K
3 K
2 K
2 K
1 K
1 K
37°C
12 K
6 K
4 K
3 K
2 K
2 K
1 K
38°C
13 K
6 K
4 K
3 K
2 K
2 K
1 K
39°C
14 K
7 K
4 K
3 K
2 K
2 K
2 K
40°C
15 K
7 K
5 K
3 K
3 K
2 K
2 K
