N7700 series:
The N7700 rear panel features ports and connectors.
Back Panel
Item Description
1.LAN2 Port  LAN2 port for connecting to an Ethernet network through a switch
or router
2.WAN/LAN1 Port  WAN/LAN1 port for connecting to an Ethernet network through a
switch or router
3.Serial Port  This port is for external UPS device
4.eSATA Port  eSATA port for high-speed storage expansion
5.USB Port  USB 2.0 port for compatible USB devices, such as USB disks, and
USB printers
6.System Fan  System fan that exhausts heat from the unit
7.Power Connector
 Connect the included power cords to these connectors
