N0503:
The N0503 supports both 2.5” and 3.5” Serial ATA (SATA) hard disks. To install a
hard disk into the N0503, follow the steps below:
1. Open front door of the N0503.
2. For 3.5” HDD
a. Get the hard drive rails and install them to your SATA hard disk(s).
b. Slide hard disks into the N0503 until they snap into place.
c. Replace the thumbscrews.
3. For 2.5” HDD
a. It has come with 2.5” HDD cage
b. Remove the 2.5” HDD tray
c. Install HDD into
d. Slide 2.5” HDD cage back in till it snap into place.
4. Replace the N0503 front cover.
Rear Panel
N0503:
The N0503 rear panel features ports and connectors.
