2. Connect the provided power cord into the universal power socket on the back
panel. Plug the other end of the cord into a surge protector socket. Press the
power supply switch to turn on the power supply.
3. Press the power button on the Front Panel to boot up the 1U4600.
To connect the N7700 series products to your network, follow the steps below:
1. Connect an Ethernet cable from your network
to the WAN/LAN1 port on the back panel of
the N7700.
2. Connect the provided power cord into the universal power socket on the back
panel. Plug the other end of the cord into a surge protector socket. Press the
power supply switch to turn on the power supply.
NOTE
If you are installing the 1U4600R, be sure to connect both power
cables. If you do not, the system will assume one power supply
has failed, and an alarm will sound.
