Thermia ATEC Planning Guide

Atec 6 kW 9 kW 11 kW 13 kW 16 kW 18 kW
Performance
11
COP
1
3,26 3,40 3,44 3,38 3,21 3,10
Heat factor
1
kW 4,73 6,22 7,68 9,10 11,40 13,26
Incoming power
1
kW 1,45 1,83 2,23 2,69 3,56 4,28
COP
2
4,32 4,38 4,68 4,35 4,12 3,97
Heat factor
2
kW 6,49 8,59 11,07 12,30 15,21 17,59
Incoming power
2
kW 1,50 1,96 2,36 2,83 3,69 4,42
COP
3
4,73 4,73 5,01 4,67 4,61 4,25
Heat factor
3
kW 6,87 8,81 10,91 12,64 15,88 18,58
Incoming power
3
kW 1,45 1,86 2,18 2,70 3,44 4,37
EER
4
2,23 2,35 2,55 2,41 2,29 2,33
Cooling output
4
kW 4,21 5,85 7,52 8,85 10,39 13,16
Incoming power
4
kW 1,88 2,49 2,95 3,67 4,53 5,65
Nominal flow
5
Heating circuit l/s 0,165 0,215 0,263 0,308 0,372 0,430
External available
pressure
9
Heating circuit kPa 60,7 59,8 58,7 56,7 96,8 95,9
Pressure
switches /pres-
sure transmitter
Low pressure
(pressure transmitter)
MPa 0,05
Operation MPa 2,85
High pressure MPa 3,1
Water volume
Water heater
6
l 180
Condenser l 1,6 2,1 2,7 2,7 3,2 4,3
Min water volume in heating system.
22
Atec Standard and Atec Plus
l 120 180 220 260 320 360
Min water volume in heating system.
22
Atec Total
l 60 90 110 130 160 180
Number of units 2
Heat pump Dimensions L x W x H mm 856x510x1272 1016x564x1477 1166x570x1557
Weight (empty) kg 125 131 150 155 185 191
Noise output level:
normal operation
7
dB(A) 61,5 61,0 61,0 62,5 67,0 74,5
Noise output level:
silent operation
7
dB(A) 60,0 59,0 59,5 61,0 64,9 70,5
Fan speed min/max rpm 500/745 500/745 425/620 465/690 625/805 770/1000
Control unit
Atec Standard
Dimensions L x W x H mm 380x204x600
Weight kg 18
Control unit
Atec Plus
Dimensions L x W x H mm
420x255x675
20
Weight kg 21
Control unit
Atec Total
Dimensions L x W x H mm
596x690x1845
21
Weight (empty) kg 106
Weight (filled) kg 286
Measurements are carried out on a limited number of circulation pumps, which can give variations in results. Tolerances in the measurement methods can also give variations.
1) At A2/W35 in accordance with EN14511 (incl. circulation pump, fan and defrosting for Atec Plus and Atec Total).
2) At A7/W35 in accordance with EN14511 (incl. circulation pump and fan for Atec Plus and Atec Total).
3) At A7/W35 Δ10K hot side in accordance with EN 255.
4) At A7/W35 according to EN 14511.
5) Nominal flow: heating circuit Δ10K.
6) Only applies to Atec Total.
7) Sound power level measured according to EN ISO 3741 at A7W35 and frost-free evaporator.
8) Only applies to Atec Plus and Atec Total.
