Thermia Calibra Installation Guide

100
200
300
400
500
600
700
800
900
1000
6 8 10 12 14 16 18
Collector Length m
Hea!ng Capacity kW
Atlas 18 - B0W35 with PEM40x2.4
DT = 3 K
DT = 4 K
DT = 3.5 K
Number of Collectors = 2
200
300
400
500
600
700
800
900
1000
6 8 10 12 14 16 18
Collector Length m
Hea!ng Capacity kW
Atlas 18 - B0W55 with PEM40x2.4
DT = 3 K
DT = 3.5 K
Number of Collectors = 2
1.6 Overview image
3a
▪
Hot water
▪
Heating system
▪
Power
▪
Brine
Installation Guide Atlas & Calibra
Thermia AB BWCA01IG0202
7
