3.2 Space requirement and recommended location
Avoid placing the heat pump in a corner or near a bedroom. The surrounding
walls can amplify the sound from the heat pump.
1930 mm
1550 mm
+5°C
OK
+30°C
300 mm
300 mm
300 mm
10 mm
600 mm
x4
1
2
3
Adjust the heat pump using the adjustable feet so that it is horizontal on the
ground.
Installation Guide Atlas & Calibra
Thermia AB BWCA01IG0202
11
