Thermia iTec XT User Manual

N
Electrical auxiliary heater for 230V, 1-N. Step 5 is highest setting.
Setting of electric auxiliary heater for 230V, 1-N. Max step 5 in the SERVICE menu:
▪
SERVICE
▪
AUX. HEATER.
▪
MAX STEP
▪
Select max step.
400V 3-N Electrical auxiliary heater
The following settings are made in the Service Menu. If not already in the Service Menu, enter the Service Menu by pressing and holding
for at least 5 seconds. Use or buttons to move up and down in the menu.
N
Electrical auxiliary heater for 400V, 3-N. Step 5 is highest setting.
Setting of electrical auxiliary heater for 400V, 3-N. Max step 5 in the SERVICE menu:
▪
SERVICE
▪
AUX. HEATER.
▪
MAX STEP
▪
Select max step.
4.7
Activate external auxiliary heater in iTec XT Standard
N
If a single power stage heater is used (on/off heater, can be an oil
burner or equivalent), this setting is the appropriate one.
The potential free outputs must be used.
If a multi power stage heater is installed, use the settings in the chap-
ter above: "Activate the electrical immersion heater in iTec XT Total,
iTec XT Compact and iTec XT Plus"
The following settings are made in the Service Menu. If not already in the Service Menu, enter the Service Menu by pressing and holding
for at least 5 seconds. Use or buttons to move up and down in the menu.
Activating the electric auxiliary heater in the SERVICE menu:
▪
SERVICE
▪
AUX HEATER
▪
MAX STEP
▪
P ( Potential free output )
▪
Press
several times to exit the Service Menu.
Commissioning
iTec XT
AWIXT01CG0102 Thermia AB
14
