Parameter Meaning
IMM. HEAT 2 Operating time for IMMERSION HEATER 2.
IMM. HEAT 3 Operating time for IMMERSION HEATER 3.
7.10 DEFROST
Parameter Meaning
DEFROSTS Total number of defrosts carried out.
BETW. 2 DEFR The operating time of the compressor in minutes between the two last defrosts.
TIME LAST DEFR The operating time of the compressor in minutes since last defrost.
7.11 CALENDAR
Parameter Meaning
CLOCK Indicate day's date and time. Used in the calendar function and in the log at the alarm.
DATE: day-month-year, example: 01-jan-2011
CLOCK: hours:minutes, example: 20:30
HOT WATER BLOCK This function is the scheduled equivalent to Operation mode AWAY.
To block hot water production. Up to eight calendar settings can be defined.
Under CALENDAR SETTING, first select the menu TIME FUNCTION if blocking should be over a continuous time
period (DATE) or be recurring (DAYS / WEEK).
Then start and stop times are selected in the TIME SETTING menu.
EVU EVU stops the heat pump and is a function that is used in certain countries to control electrical consumption. Up
to eight calendar settings can be defined
Under CALENDAR SETTING, first select the menu TIME FUNCTION if stop should be over a continuous time peri-
od (DATE) or be recurring (DAYS / WEEK).
Then start and stop times are selected in the TIME SETTING menu.
SILENT MODE Function where the noise level of the heat pump fan is reduced. Up to eight calendar settings can be defined.
Under CALENDAR SETTING first select the menu TIME FUNCTION if reduction should be over a continuous time
period (DATE) or be recurring (DAYS / WEEK).
Then start and stop times are selected in the TIME SETTING menu.
TEMP. REDUCTION Function for reduction of temperatures. The new setpoints are those values that are stated for heat curve, shunt
groups and buffer tank in the information menu. Up to eight calendar settings can be defined.
Under CALENDAR SETTING first select the menu TIME FUNCTION if reduction should be over a continuous time
period (DATE) or be recurring (DAYS / WEEK).
Then start and stop times are selected in the TIME SETTING menu.
CONCRETE PROG. Hysteris is how much the temperature drops until re-start of the heat pump. 1-5 factory setting: 2
Add up to 10 temperature points to get the proper temperature on the concrete over time in the concrete dry-
ing program. Uses fixed supply line temperatures that is connected to a concrete curve for the concrete drying.
Start with adding Point 1 add the number of days ( 1-40 ) then add the set supply line temperature (15°C-55°C),
then choose the next connected temperature for POINT 2 and follow the same procedure as previously for the
following points. Contact your concrete supplier for the proper settings for concrete drying.
7.12 ALARM
Parameter Meaning
NAME ALARM Displays information about up to 10 alarms and alarm times.
NAME: Name of the alarm, example: AUX. HEATER
TIME: hours:minutes, example 20:45
DATE: day-month-year, example 13-jan-11
Commissioning iTec XT
AWIXT01CG0102 Thermia AB
34
