Thermo King SLXi Spectrum Maintenance Manual

Structural Maintenance 12-5
UNIT INSTALLATION
All nuts that hold the unit to the trailer are accessible using an impact wrench with a 25 cm extension, ball-type swivel and a
deep-well socket.
NOTE: The nuts for mounting the unit should be elastic stop nuts (Nylock type)
Unit Installation – SL and SLe
1. Reach this top nut through the hinged condenser grille.
2. SL and SLe: Reach the top center nut by opening the control panel side condenser grille and removing the blower access panel.
3. Reach this top nut through the hinged condenser grille.
4. Reach this centre nut through the hinged condenser grille.
5. Reach this bottom nut by opening (SL and SLe) the control panel.
6. Reach the centre nut through the center of the engine compartment.
7. Reach this bottom nut through the front access door.
8. Reach this centre nut through the hinged condenser grille.
