V-200/V-300 and Spectrum
Fuse 6: Condenser Fan 1/2 2 amps 2 amps
Fuse 8: (Spectrum Only) EVAP2 Liquid Solenoid
Valve (PS2), EVAP1 Liquid Solenoid Valve (PS3),
EVAP2 Defrost Hot Gas Solenoid Valve (PS4), Drain
Heaters 3 and 4 (HT3, HT4)
20 amps 10 amps
Fuse 9: (Spectrum Only) Evaporator Fan 3 15 amps 10 amps
Fuse 10: (Spectrum Only) Evaporator Fan 4 15 amps 10 amps
Fuse 11: Drain Heaters (H1 and H2) 2 amps 2 amps
Fuse 20: Transformer AC Power Supply (located at
compressor motor contactor in condenser section)
4 amps 4 amps
Fuse 21: Battery Power Supply (located in 2 wire
near battery)
40 amps 40 amps
V-500/V-600 and Spectrum
Fuse 6: Condenser Fan 1/2 10 amps 7.5 amps
Fuse 8: (Spectrum Only) EVAP2 Liquid Solenoid
Valve (PS2), EVAP1 Liquid Solenoid Valve (PS3),
EVAP2 Defrost Hot Gas Solenoid Valve (PS4), Drain
Heaters 3 and 4 (HT3, HT4)
20 amps 10 amps
Fuse 9: (Spectrum Only) Evaporator Fan 3 15 amps 10 amps
Fuse 10: (Spectrum Only) Evaporator Fan 4 15 amps 10 amps
Fuse 11: Drain Heaters (H1 and H2) 2 amps 2 amps
Fuse 17: Drain Heaters (H3 and H4) 2 amps 2 amps
Fuse 20: Transformer AC Power Supply (located at
compressor motor contactor in condenser section)
4 amps 4 amps
Fuse 21: Battery Power Supply (located in 2 wire
near battery)
50 amps
(Single Temp)
60 amps (Multi-
Temp)
Fuse 31: Condenser Fan Motor 2 (CFM2) (located in
CF2 wire near terminal strip in condenser section)
16 amps 10 amps
