Specifications
16
Coolant System Capacity:
T-600R and T-800R with Tube and Fin
Radiator Coil (ending 6/12)
T-600R and T-800R with Micro-Channel
Radiator Coil (starting 6/12)
T-1000R with Tube and Fin Radiator
Coil (ending 6/12)
T-1000R with Micro-Channel Radiator
Coil (starting 6/12)
4.5 quarts (4.3 liters) with coolant expansion tank
4.9 quarts (4.6 liters) with coolant expansion tank
5.0 quarts (4.7 liters) with coolant expansion tank
5.4 quarts (5.1 liters) with coolant expansion tank
Coolant Expansion Tank Cap Pressure 15 psig (103 kPa)
Belt Tension
Belt Tension No. on TK Gauge
P/N 204-427
Frequency Gauge P/N 204-1903
Setting Where Applicable
New Belt Field Reset New Belt Field Reset
Water Pump Belt 40 40
Engine/Electric Motor (Jackshaft) 81 77 62 Hz 55 Hz
Electric Motor (Jackshaft)/Compressor Automatically tensioned by tensioner position. See “Belts” in Engine
Maintenance Chapter.
Engine Clutch
Engagement 600 ± 100 RPM
Dynamic Torque 66 ft-lb (89.5 N•m) minimum @ 1600 RPM
Refrigeration System
Compressor Model: T-600R and T-800R
T-1000R
Thermo King X214
Thermo King X426 LSC5
Refrigerant Charge:
T-600R with Tube and Fin Condenser
Coil (ending 6/12)
T-600R with Micro-Channel Condenser
Coil (starting 6/12)
T-800R with Tube and Fin Condenser
Coil (ending 6/12)
T-800R with Micro-Channel Condenser
Coil (starting 6/12)
T-1000R with Tube and Fin Condenser
Coil (ending 6/12)
T-1000R with Micro-Channel Condenser
Coil (starting 6/12)
8.0 lb (3.6 kg) R-404A
7.0 lb (3.2 kg) R-404A
8.5 lb (3.9 kg) R-404A
7.0 lb (3.2 kg) R-404A
9.0 lb (4.1 kg) R-404A
7.5 lb (3.4 kg) R-404A
*Compressor Oil Charge:
X214 in T-600R and T-800R
X426 in T-1000R
3.2 quarts (3.0 liters)
4.3 quarts (4.1 liters)
Compressor Oil Type Ester base P/N 203-513 required
Suction Pressure Regulator Valve Setting:
T-600R
T-800R
T-1000R
28 to 31 psig (193 to 214 kPa)
35 to 37 psig (241 to 255 kPa)
21 to 23 psig (145 to 159 kPa)
Engine (Continued)
