Specifications
18
Damper Solenoid 5.7 2.2
Condenser Inlet Solenoid (CIS) 1.8 6.9
Hot Gas Solenoid (HGS) 1.1 11.3
Purge Valve (PV) 1.1 11.3
Starter Motor (No Load Bench Test) 90
Electrical Standby (Model 50 Units Only)
T-600R and T-800R Electric Motor and Overload Relay
Voltage/Phase/Frequency Horsepower Kilowatts rpm Full Load
(amps)
Overload Relay
Setting (amps)
230/3/50 6.0 4.5 1460 17.0 19
208-230/3/60 7.2 5.4 1765 19.4 22
400/3/50 6.0 4.5 1460 9.8 11
460/3/60 7.2 5.4 1765 9.7 11
T-1000R Electric Motor and Overload Relay
Voltage/Phase/Frequency Horsepower Kilowatts rpm Full Load
(amps)
Overload Relay
Setting (amps)
230/3/50 10.0 7.5 1460 22.5 25
208-230/3/60 12.0 8.9 1750 28.8 32
400/3/50 10.0 7.5 1460 17.0 16
460/3/60 12.0 8.9 1750 14.4 16
Electric Heater Strips (Optional)
Number 3
Watts 750 watts (each)
Resistance 71 ohms (each)
Standby Power Requirements
Supply Circuit Breaker:
T-600R and T-800R 200-230/3/50-60
T-1000R 200-230/3/50-60
All 380-460/3/50-60
30 amps
50 amps
20 amps
Extension Cord Size: Up to 50 ft—10 gauge
75 ft—8 gauge
Electrical Components (Continued)
Component Current Draw (Amps)
at 12.5 Vdc
Resistance
(Ohms)
To Next Page
