Serial Communications 3104
REC XXXXX 3-10
- PRINTER SCROLL 6 -
Print time # 1
time HH:MM
ENTER ON/OFF NEXT
- PRINTER SCROLL 7 -
Print alarms
> No <
CHOICE ENTER
- PRINTER SCROLL 7 -
Print alarms
> No <
CHOICE ENTER
Password: Operator
Default: OFF
Min: 00:00
Max: 23:59
3.4.5 Define Printing Format
By selecting YES in the following screen, the system is instructed to print one line
each time a new alarm condition occurs. The alarm is printed as follows:
xx-xx-xxxx yy:yyz
kkkkkkkkkkkkkkkkkkkk
where:
xx-xx-xxxx Day, Month, Year, printed according to the local
format as defined in Main Menu 2 - Display.
yy:yyz Hour, Minutes, am/pm printed according to the local
format as defined in Main Menu 2 - Display
kkkkkkkkkkkkkkkkkkkk Alarm message, same message
appearing on the screen.
For example:
09-10-2002 8:14a
High rate
Password : Service
Default: NO
Selections: NO, YES
If YES is selected, the system prints all alarms that have been set to alarm in the Alarm scroll.
There are three ways for defining the printing format. The first is to use the predefined format.
(See Section 3.3).
Select DEFAULT if you want the predefined format. Select USER DEFINED if you want to set
up your own format.
