Thermon GENESIS User Manual

44
7
Circuit Settings
Function
Code(s)
Base Mem
Location
Description Allowed Values
Decimal
Hex
Add Circuit # x 100 to Base Memory Location to get the MODBUS Data Address
Circuit 1's Heater Current = 2 + 1 *100 = 102 (0x0066)
Circuit 72's Heater Current = 2 + 72*100 = 7202(0x1C22)
(Values below represent Circuit 1's location)
4 100 0x064
Control Temperature for
the DCM
RTD Reading for the
DTM
Value x10
(1)
This location on the DCM is the temperature
that it has decide to control off.
This location on the DTM is an RTD reading.
4 101 0x065
Which DTM and RTD
that the circuit is
controlling from
low Byte = DTM address 1-199
High Byte = RTD from DTM 1-6
4
102
0x066
Heater Current Value x 10 (A)
(2)
4 103 0x067
Ground Current Value in (ma)
4
104
0x068
Heater Percent On Range = 0-100%
4
105
0x069
Alarms
Bit definitions
(3)
0x8000(bit) High Current Trip
0x4000(bit) Programing error
0x2000(bit) Current over .5A when circuit off
0x1000(bit High Ground Trip bit
0x0800(bit) RTD Fault No Communication for
all assigned RTD's
0x0400(bit) High Temperature trip
0x0200(bit) RTD Fault ( all assigned RTD's in
fault)
0x0100(bit) Not Used
0x0080(bit) High Current
0x0040(bit) Low Current
0x0020(bit) Circuit Fault
0x0010(bit) High ground current
0x0008(bit) RTD Fault No Communication
0x0004(bit) High temperature Alarm
0x0002(bit) RTD Fault (one or more assigned
RTD's in fault)
0x0001(bit) Low temperature Alarm
