Thermon GENESIS User Manual

45
8
Circuit Settings
Function
Code(s)
Base Mem
Location
Description Allowed Values
Decimal
Hex
Add Circuit# x 100 to Base Memory Location to get the MODBUS Data Address
Circuit 1's Maintain Temp = 1 + 1 *100 = 101 (0x0065)
Circuit 72's Maintain Temp = 1 + 72*100 = 7201(0x1C21)
(Values below represent Circuit 1's location)
03/06 100 0x0064 Alarm
Acknowledge
Bit Value
(3)
0x8000(bit) High Current Trip
0x4000(bit) Programing error
0x2000(bit) Current over .5A when circuit off
0x1000(bit) High Ground Trip bit
0x0800(bit) RTD Fault No Communication
for all assigned RTD's
0x0400(bit) High Temperature trip
0x0200(bit) RTD Fault ( all assigned
RTD's in fault)
0x0100(bit) Not Used
0x0080(bit) High Current
0x0040(bit) Low Current
0x0020(bit) Circuit Fault
0x0010(bit) High ground current
0x0008(bit) RTD Fault No Communication
0x0004(bit) High temperature Alarm
0x0002(bit) RTD Fault (one or more assigned
RTD's in fault)
0x0001(bit) Low temperature Alarm
03/06
101
0x0065
Maintain temp
10x True Value
03/06
102
0x0066
Control Band
10x True Value
03/06 103 0x0067 High Temperature
Trip Alarm
03/06
104
0x0068
High Temp Alarm
03/06
105
0x0069
Low Temp Alarm
10x True Value
03/06 106 0x006A High Ground
Fault Trip Alarm
Value in (ma)
03/06 107 0x006B High Ground
Fault Alarm
Value in (ma)
03/06 108 0x006C High Current
Alarm Trip
10x True Value (A)
03/06 109 0x006D High Current
Alarm
10x True Value (A)
03/06 110 0x006E Low Current
Alarm
10x True Value (A)
