Thermon GENESIS User Manual

46
9
Circuit Settings
Function
Code(s)
Base Mem
Location
Description Allowed Values
Decimal
Hex
Add Circuit# x 100 to Base Memory Location to get the MODBUS Data Address
Circuit 1's Maintain Temp = 1 + 1 *100 = 101 (0x0065)
Circuit 72's Maintain Temp = 1 + 72*100 = 7201(0x1C21)
(Values below represent Circuit 1's location)
03/06 111 0x006F Circuit Enable/
Status
Bit definitions
0x0008(bit) Heater Forced Off = 1 normal = 0
0x0004(bit) Heater Forced On = 1 normal = 0
0x0002(bit) Heater Tripped = 1 normal = 0
0x0001(bit) Heater Enabled = 1 , Disabled = 0
03/06 112 0x0070 Control Type 0 = On/Off
1 = On/Off with a Soft Start
2 = Proportional
3 = Ambient Proportional Mechanical
4 = PID
03/06
113
0x0071
Number of RTDs
per Circuit
1 to 20
03/06
114
0x0072
RTD Fault power
Range = 0 to 100%
03/06
115
0x0073
Power Clamp
Range = 0 to 100%
(1)
Temperature Ranges:
Read:
Write:
RTD Open:
RTD Fault:
For °C, integer value read as -1289 to 6000 divided by 10 results in a
temperature in the range of -128.9 to 600.0°C.
For °F, integer value read as -2000 to 11120 divided by 10 results in a
temperature in the range of -200.0 to 1112.0°F.
For °C, temperature in the range of -128.9 to 600.0°C multiplied by 10 results in
integer value from -1289 to 6000 to be written.
For °F, temperature in the range of -200.0 to 1112.0°F multiplied by 10 results in
integer value from -2000 to 11120 to be written.
If greater than 600.0°C or 1112.0°F
If less than -128.9° C or -200.0°F
(2)
Current Ranges
Read:
Write:
Integer value read as 0 to 12500 divided by 100 results in a current in the range
of 0.00 to 125.00 Amps.
Current in the range of 0.00 to 125.00 Amps multiplied by 100 results in an
Integer value from 0 to 12500 to be written.
