10
770 600
725
173
80
Operating instructions BW3-CTMC + BW3-RF
© 2011 by Thermoplan, subject to change
Capacities
Products (per hour): 240 espressos / 200 coffee / 18l hot water /
130 cappuccino / 140 lattino / 90 choco products
Refrigerator: Milk container up to 5 litres (gross volume 6.5 litres)
Electrical connection /
Power
220-240 V / 16 A / 50/60 Hz / 3‘200 - 3‘800 W
Coffee boiler pressure 1.17 MPa (11.7 bar)
Mains water pressure 0.2 - 0.4 MPa (2 - 4 bar)
Dimensions (W/D/H)
770x600x725 mm (B / T / H) with small bean hoppers
770x600x750 mm (B / T / H) with large bean hoppers
Weight 94 kg
Noise emission <70 dB
3 General notes
3.2 Technical data
Depth (view from side)
Height / width (view from front)
