ThinkPad T60 - Page 98

For models with 15.0-in. LCD:
3
2
3
3
4
4
4
4
Step Screw (quantity) Color Torque
3 M2 × 5 mm, flat-head, nylon-coated (3) Black 0.167 Nm
(1.7 kgfcm)
In step 4, strip off the tapes securing the antenna cables, and release the cables
from the cable guides of the frame.
When installing: Do not pinch the antenna cables when you attach the LCD
connector.
(continued)
Removing and replacing a FRU
92 MT 1951, 1952, 1953, 1954, 1955, 1956, 2007, 2008, 2009, 2613, 2623, and 2637
