5 Connections and controls
1 [VOLUME]
Volume control for the headphone output of the device
2 [POWER]
Main switch. Turns the device on and o.
3 [KIT/VOICE]
Button to open the menus ‘KIT’ and ‘VOICE’
Short press: opens the ‘KIT’ menu.
Press and hold: opens the ‘VOICE’ menu.
4 Jog wheel to select a drum kit and quickly set values
5 [CLICK]
Turns the metronome on and o.
6 [ST/SP]
Starts or stops song playback.
Front panel
Connections and controls
e-drum module
10
